Payload Sand And Slurry Pump

Payload-Sand-And-Slurry-Pump-Image

Efficient Dredging

The DAE Pumps Payload Electric Sand & Slurry Pump is a robust and dependable solution for dredging and solid transportation. Designed to withstand challenging conditions, this pump is capable of moving up to 2,000 cubic meters of solids per hour. Its advanced non-clogging suction system efficiently handles solids up to 3.9 inches in diameter, transporting up to 30% solid content through a 16-inch discharge.

Versatile and High-Performance Pumping Solution

As part of the DAE Pumps submersible sand and slurry pump series, the Payload electric slurry pump is a versatile choice for a wide range of dredging applications. It offers flexible deployment options, including cable suspension or excavator mounting, to suit different project requirements. With optional features like an agitator or water jetting ring, the pump is further enhanced to tackle organic materials such as seaweed and grass, ensuring optimal suction and uninterrupted operation.

Comprehensive Dewatering Solutions

At Pumps For Jamaica, we deliver more than just products; we offer complete solutions to meet all your dewatering needs. Known for their outstanding durability and efficiency, our pumps are backed by a commitment to addressing a wide range of applications. Featuring sealed and modular designs, our pumps ensure user-friendly operation and hassle-free maintenance, resulting in reliable performance and easy servicing. This emphasis on functionality and customer satisfaction makes DAE Pumps the go-to choice for diverse dewatering projects across various industries.

DAE-Pumps-logo
Payload-Sand-And-Slurry-Pump-Image

Key Features

  • Highly Durable and Abrasion Resistant Dredge Pump
  • Multiple Size Pump Options: 3″, 4″, 6″, 8″, 10″, 12″, 14″, and 16″
  • Capacity: Up to 2000 Cubic Meters Per Hour
  • Solid Handling: Pumps up to 30% Solids
  • Operational Depth: Up to 250 meters
  • Robust Electric Motor: Provides strong torque and long life

Specifications

  • Max Capacity: 2860 GPM (650 m³/h)
  • Max Head: 89.5’ (27m)
  • Impeller Diameter / Type: 16” (405mm) / 3 Blades Closed
  • Discharge Size: 12” (300mm)

  • Solid Handling: 3.6” (90mm)

Materials

  • Casing: Spheroidal Cast Iron EN-GJS500-7 (EN 1563)
  • Motor Housing: Cast Iron EN-GJL-250 (EN 1561)
  • Wear Parts: High Chrome EN-GJN-HV600 (XCr18) (EN 12513)
  • Main Shaft: High Tensile Steel 39NiCroMo3 (AISI 9840)

Motor

  • Motor Displacement: 9.8 cu. Inch (160 cc)
  • Max. Oil Flow Rate: 72 GPM (270 l/min)
  • Max. Pressure: 4351 PSI (300 bar)
  • Power: 185 HP (475 kW)

  • Speed: 1450 RPM

Seals / Lubricant

  • Motor Side Seals: 2 Lip Seals (BUNA)
  • Impeller Side Seals: 5 Lip Seals (3 BUNA + 2PTFE) + 1 V-ring (TPU)

  • Oil type: ISO 320
