Advanced Hydraulic Solutions

The DAE Pumps Hauler Hydraulic Sand & Slurry Pump is engineered for superior durability and efficiency, making it an ideal choice for tackling tough materials and large-scale dredging projects. With a capacity to move up to 2,000 cubic meters of solids per hour, this pump excels in the most demanding tasks. Its innovative non-clogging suction design handles solids up to 3.9 inches in diameter, efficiently transporting material through a 16-inch discharge with up to 30% solid content. As part of DAE Pumps’ versatile hydraulic line, the Hauler is known for its exceptional performance and adaptability.

Efficient and Flexible Pumping for Demanding Applications

Designed for versatility, the Hauler Hydraulic Sand & Slurry Pump is an essential solution for a wide range of dredging applications. It offers multiple deployment options, including cable suspension and excavator mounting, to accommodate different project needs. The pump’s flexibility is further enhanced with customization options like an agitator or water jetting ring, making it highly effective at breaking down organic matter such as aquatic vegetation. These features ensure continuous operation and improve the pump’s adaptability to various challenging conditions.

Comprehensive Dewatering Solutions

At Pumps For Jamaica, we deliver more than just products; we offer complete solutions to meet all your dewatering needs. Known for their outstanding durability and efficiency, our pumps are backed by a commitment to addressing a wide range of applications. Featuring sealed and modular designs, our pumps ensure user-friendly operation and hassle-free maintenance, resulting in reliable performance and easy servicing. This emphasis on functionality and customer satisfaction makes DAE Pumps the go-to choice for diverse dewatering projects across various industries.

DAE-Pumps-logo
3cv-Hydraulic-Pumps-For-Sand-And-Mud-image

Key Features of the Pump

  • Durability and Abrasion Resistance: Built to withstand high abrasion, the Hauler pump ensures a long operational lifespan, even in the toughest conditions.
  • Size Options: Available in sizes ranging from 3 to 16 inches, allowing for versatility across various applications.
  • High Capacity: Capable of moving up to 2,000 cubic meters of solids per hour, making it ideal for large-scale, high-volume tasks.
  • Efficient Solid Handling: Designed to pump materials with up to 30% solid content, ensuring smooth operation without clogging.
  • Operational Depth: Engineered to perform effectively at depths of up to 250 meters, providing reliable service in deep dredging projects.
  • Powerful Hydraulic Motor: Delivers strong torque for consistent performance, ensuring the pump’s long-term reliability.

The Hauler Hydraulic Sand & Slurry Pump stands out for its exceptional performance and adaptability, making it the perfect solution for challenging dredging and dewatering tasks.

Specifications

  • Max Capacity: 2860 GPM (650 m³/h)
  • Max Head: 89.5’ (27m)
  • Impeller Diameter / Type: 16” (405mm) / 3 Blades Closed
  • Discharge Size: 12” (300mm)

  • Solid Handling: 3.6” (90mm)

Materials

  • Casing: Spheroidal Cast Iron EN-GJS500-7 (EN 1563)
  • Motor Housing: Cast Iron EN-GJL-250 (EN 1561)
  • Wear Parts: High Chrome EN-GJN-HV600 (XCr18) (EN 12513)
  • Main Shaft: High Tensile Steel 39NiCroMo3 (AISI 9840)

Motor

  • Motor Displacement: 9.8 cu. Inch (160 cc)
  • Max. Oil Flow Rate: 72 GPM (270 l/min)
  • Max. Pressure: 4351 PSI (300 bar)
  • Power: 185 HP (475 kW)

  • Speed: 1450 RPM

Seals / Lubricant

  • Motor Side Seals: 2 Lip Seals (BUNA)
  • Impeller Side Seals: 5 Lip Seals (3 BUNA + 2PTFE) + 1 V-ring (TPU)

  • Oil type: ISO 320
